PCI Express SATA Adapter 2 Port SATA 3.0 6Gbps Controller

Product interface: PCI-E 1X 4X 8X 16X
Chipest: ASM1061
Support specification: SATA3.0 7PIN
Bus interface: PCI-Express X1 slot
Extension interface: 2 SATA3.0 interfaces
System requirements: there is an available PCI Express X1 slot, while supporting PCI-E X2 X4 X8 X16
Operating system: Windows10/8/7 (32/64 bit) / Vista (32/64 bit) / XP/2003/2008/linux

SKU: SH-2.3-27

5 in stock

30.00 inc. VAT

5 in stock


  • Compliant with Serial ATA Specification 3.0, down compatible with SATA2.0 SATA1.0.
  • Conformance to PCI-Express v2.0 specifications, down compatible with PCI-Express v1.0.
  • Supports communication speeds of 6.0Gbps,3.0Gbps and 1.5Gbps.
  • Supports Gen 1i,Gen 2i,Gen 2m, Gen 2x and Gen 3i.
  • Supports two SATA Ports.
  • Supports AHCI 1.0 and IDE modes.
  • Supports Native Command Queuing(NCQ)
  • Supports Port Multiplier FIS based switching or command based switching.
  • Supports Hot Plug and Hot Swap.
  • Compatible with SATA 6G,3G and 1.5G Hard Drives
